Supports USB hosts and devices up to USB 5Gbps; backwards compatible with USB1, USB2

Individually enable/disable any of 8 downstream ports

Measure voltage and current on each downstream port

Hi-Speed data, SuperSpeed data and power lines can be separately enabled for each downstream port

Set programmable current limits for each downstream port (up to 4A)

Dedicated Control Port for software control; independent of the selected upstream port

Select between two (2) host connections

All ports support USB link speeds up to 5Gbps

Detect established link speed on each port: SuperSpeed (5Gbps) or Hi-Speed (480Mbps)

Supply up to 5A per port; measure up to 4A

Set enumeration delay for discovery of attached downstream devices

Backward compatible with USB 2.0 and USB 1.x devices

Boost USB 2.0 upstream and downstream signal levels

DIN-rail mountable

Alternate Euro-style terminal block power input connector

Certified to +/-15kV ESD strikes (IEC61000-4-2 level 4)

Overvoltage and reverse current protected Vbus outputs

Monitor voltage and current on any/all ports

Maintain selectable control of data, SS lines, power lines for any port

Enable/Disable any downstream port
